MiniGrip Round GR50

$121.33

This MiniGrip gripper has a 15mm thick foam, a diameter that measures 50mm and is available in a regular and high flow orifice versions. Choose regular flow to limit vacuum loss when using multiple Minigrips with a single vacuum source. Choose a high flow design when handling high porosity materials.

NOTE: Ships from manufacturer, lead time 2 weeks.

SKU: N/A Categories: ,

The table below lists the performance specifications for the MG GR50 foam gripper.

Model NumberHolding Force lbs (N) for 70% Vacuum*
MG.PG.GR50Non-Porous (Steel)3.8 (17)
Semi-Porous (Wood)3.1 (14)
Porous (Cardboard)2.4 (11)
* Holding force is based on gripper being fully covered. Safety factor of 2 already applied.
